CCD Battery polarity detector

Dimension: 600mm*500mm*1700mm

Application: cylindrical cells

Power: 1.2KW

Weight: 120KG

Driving power: Electric

National hotline

13451760748

Introduction

Technical parameter

Power

220V   50HZ   1200W

Application

All cylindrical

Edit

Support CAD import/manual/array three methods

Controller parts

7 inch touch screen PLC programmer and stepper motor

Feeding method

Manual / Auto

Driving power

Electric

Productivity

Single shot method ≤ 0.4 seconds, one shot direction ≤ 2 seconds

Dimension

L600×W500×H1700mm

Effective form

450*350(customizable)

Control device

Embedded motion control system + man-machine screen

Weight

120KG


Features

1.It can be used for all cylindrical cells, 18650.27700.26650.26800 and so on.

2.Fast line change, CAD position data import, easy to get in two minutes.

3.Quick mold change, quick release screws in position, just move the baffle.

4.Save money, don’t need any vehicles, just put it in the streamline.

5.Stable, the misjudgment of a single camera is less than one in ten thousand.

6.The reliability is strong, and the standard machine has been verified and updated many times.
